Tipe Mesin |
4-stroke SOHC 2-Valve |
Tipe Transmisi |
Manual, 4-speed |
Tipe Kopling |
Wet, Multiple With Coil Spring |
Tipe Starter |
Electric |
Diameter x Langkah |
50 x 63,1 mm |
Volume Langkah |
124 cc |
Daya Maksimum |
7,2 kW / 7.500 rpm |
Torsi Maksimum |
10,4 nM / 6.250 rpm |
Busi |
- |
Sistem Bahan Bakar |
PGM-FI |
Pengapian |
- |
Tipe Pendingin |
Air-cooled |
Perbandingan Kompresi |
10 : 1 |
Pola Perpindahan Gigi |
- |
Jenis Pelumas |
- |
Tipe Rangka |
Backbone, Steel |
Tipe Suspensi Depan |
Telescopic Front Suspension |
Tipe Suspensi Belakang |
Twin Rear Suspension |
Ukuran Ban Depan |
70/90-17 M/C 38P (Tubeless) |
Ukuran Ban Belakang |
80/90-17 M/C 50P (Tubeless) |
Tipe Rem depan |
Hydraulic Disc |
Tipe Rem Belakang |
Mechanical Leading Trailing |
Sistem Pengereman |
- |
Panjang x Lebar x Tinggi |
1.915 X 720 X 1.000 mm |
Jarak Sumbu Roda |
1.245 mm |
Jarak Terendah Ke Tanah |
125 mm |
Ketinggian Tempat Duduk |
780 mm |
Berat Kosong |
110 kg |
Kapasitas Tangki Bahan Bakar |
3,7 L |
Kapasitas Minyak Pelumas |
0,8 L (Periodic Exhange) |
Tipe Baterai Atau Aki |
12V-3Ah |
Sistem Pengapian |
Full Transisterized |
Tipe Busi |
NGK CPR7EA-9S |
Power Charger |
- |
